FREEBEAR福力百亚举模器AFU-3836-5适用于气动悬浮搬运

苏州上野刘燕-185-2015-9819

FREEBEAR AFU-3836-5 是一款角槽插入式气动气浮万向球单元，用于重载模具、工装的气动悬浮搬运与定位。

一、基本参数

尺寸与结构：总长 310mm，L1 为 264mm，间距 P 为 200mm，自重 2.5kg，球材质 SUJ2、球座 SCM415、本体钢。

气压与负载：使用气压 0.3–0.6MPa；整体负载在 0.3/0.4/0.5/0.6MPa 下分别为 0.98kN(99.4kgf)、1.20kN(122.4kgf)、1.55kN(158.1kgf)、1.95kN(198.8kgf)。单球负载约 0.20kN(19.9kgf)（0.3MPa）。

行程：万向球上浮行程约 4mm

二、工作原理与特点

1.气动升降：通压缩空气后活塞顶起万向球，托起工件实现低摩擦平移（μ≤0.03）；断气后靠自重或强制排气缩回，工件落位定位。

2.安装形式：方槽/U型槽嵌入机床工作台，多条可拼接，公式 A=45 + L1总计 + 连接数(mm)。

3.优势：纯气动无电机磨损、嵌入式不干涉加工、可毫米级微调对位，适配换模与精密定位。

三、典型应用

机床重型模具快速换模、大型工装板平移定位、冲压/注塑模具搬运及自动化工件校准。

四、使用注意

压缩空气须过滤干燥（含水量≤0.01g/m³），环境 0–60°C 避结露，不使用时排空气
